LED Dual Mode Nano-plastic T8 Lamps

LED Dual Mode Nano Plastic T8 Lamps
  • Replaces T8 fluorescent lamps
  • No ballast required – Powered by direct line input (120–277VAC)
  • 50,000 hour L70 rated life
  • Over 50% energy savings versus 4ft. fluorescent
  • Up to 140 Lumens/watt
  • Beam angle 320°
  • Mercury free DLC listed – qualifies for all applicable utility and government rebate/incentive programs
  • 5 Year Warranty

Specifications

Model EL-ZY-T8P-10W600 EL-ZY-T8P-12W1200 EL-ZY-T8P-15W1200
Tube Length
2' 4'
Power 10 watts 12 watts 15 watts
Lumen Output 1400 1670 2160
Color Temp 3000K, 3500K, 4000K, 4500K, 5000K
Operating Temperatures -30°C to +40°C
Beam Angle 330°
Input Voltage Type B, Direct 120 - 277VAC
CRI > 80 Ra
Rated Life > 50,000 hours

Dual mode lamps work with or without the existing fluorescent ballasts.
To retrofit a 4ft. fluorescent fixture, choose to either leave the existing ballast in place “as is”, or remove the ballast completely from the circuit
by simply bypassing it to run directly off incoming 120-277VAC.

Download Catalog Sheet » T8 Safety Labels » Installation Instructions »
