MS Street Light 3

MS Series Parking Lot Street Light Fixtures

LED Parking Lot and Street Lights

Parking lot and street light fixtures for general area and roadway pole mounted applications. Ideal for municipalities, commercial buildings, condominiums, parking lots, hotels, museums, retail plazas/malls, etc.

A variety of styles and light output levels available to accommodate any application. Will replace from 250W to 1000W HID fixtures.

IP66 rated for harsh and wet environments.

MS Street Light Fixture Instructions on adjusting it MS Series Parking Lot Street Light Fixture


Model EL-MS-SL-70W EL-MS-SL-105W EL-MS-SL-150W EL-MS-SL-200W EL-MS-SL-250W EL-MS-SL-300W EL-MSSL-350W
Power 70W 105W 150W 200W 250W 300W 350W
Lumen Output 8,600 to 9,000 12,500 to 13,400 18,800 to 21,000 25,000 to 27,000 30,000 to 35,000 36,000 to 42,000 42,500 to 52,500
Input Voltage 120 - 277VAC or 347 - 480VAC
Controls 0-10V dimming available. Photo cell/motion sensor optional
Beam Angle Standard: Type III, IV, V
Color Temp 3000K     3500K     4000K     5000K
Physical Die cast aluminum housing with standard dark bronze finish
Special order finishes: black, white, silver grey
Multiple mounting options: PC lens
IP Rating IP66
Rated Life > 50,000 hrs. > 100,000 hrs.

Download Catalog Sheet » Mounting Accessories » Specifications & Dimensions »
