Products - Interior

T5 LED Lamps

T5 LED lamps make replacing Fluorescent T5 tubes affordable and easy

Option 1

Direct Drive LED T5 Lamps

Emium “ballast by-pass” LED T5 Lamps eliminate the need to maintain aging T5HO ballasts.

  • Uses only 24-Watts
  • 50,000 hour L70 rated life
  • Over 50% energy savings versus T5 HO 54W fluorescent
  • Environmentally friendly, mercury free

Option 2

Plug & Play LED T5 Lamps

Emium Plug & Play LED T5 Lamps replace fluorescent T5 tubes without removing the existing T5 ballast.

  • Available in 2,3, & 4 ft. lengths/14, 18, & 28-watts
  • 50,000 hour L70 rated life
  • Direct replacement for T5HO lamps
  • Compatible with programmable start T5HO electronic ballasts.
LED T5 lights in warehouses

Specifications

Model EL-SE-T5-24W4FT-BPTE EL-SE-T5-14W2FT EL-SE-T5-18W3FT EL-SE-T5-28W4FT
Input Voltage 100 – 277VAC
Type B - Line Direct/Ballast By-pass
Ballast Compatible
Type A - For use with programmable start T5HO electronic ballasts
Tube Length 46"
Note: The 4 ft. T5 tube is actually 46" in length to fit in a standard T5 fixture
22" 34" 46"
Power 24W 14W 18W 28W
Lumen Output 3,500 1,400 - 1,600
(Ballast Dependent)
1,800 - 2,050
(Ballast Dependent)
2,800 - 3,200
(Ballast Dependent)
Color Temperatures 3000K, 4000K, 5000K
Operating Temperature -4°F to +113°F
Beam Angle 160°
CRI > 80 Ra
Rated Life > 50,000 hrs.

Download Catalog Sheet »
